Download Komatsu D155AX-6 Bulldozer Field Assembly Instruction GEN00049-07

Execute safe and efficient on-site erection with the official Komatsu D155AX-6 Bulldozer Field Assembly Instruction (Publication GEN00049-07). This comprehensive technical guide details step-by-step installation sequences for the main frame, tracks, final drives, operator cab, blade assemblies, ripper attachments, and hydraulic systems. Designed for field service technicians, rigging crews, and heavy equipment mechanics, manual GEN00049-07 includes vital lifting diagrams, torque specifications, hydraulic line routing, and pre-commissioning safety inspection checklists to ensure precise crawler dozer deployment.

PUBLICATION NO : GEN00049-07
SERIAL NUMBERS : 80001 AND UP
FILE SIZE : 12.53 MB
TOTAL PAGE : 127
LANGUAGE : ENGLISH

MODEL COVERED:-
D155AX-6 Bulldozer

CONTENT INCLUDED:-
SPECIFICATIONS
PRECAUTIONS FOR FIELD ASSEMBLY
ASSEMBLY PROCEDURE, NECESSARY EQUIPMENT, AND SCHEDULE
LAYOUT OF KIT
STYLE FOR TRANSPORTATION
LIST OF TOOLS FOR FIELD ASSEMBLING
TIGHTENING TORQUE
COATING MATERIALS

INSTANT DOWNLOAD ACCESS
